SS200

The SS200 balances stabilitiy with maneuverability for a unit that takes traction and handling to the next level. An adjustable operator platform with suspension optimizes operator comfort and increases productivity, allowing customer operation in a variety of conditions. The SS200 unique design allows for quick operator exit and re-entry, with the PRO automatically disengaging when the operator leaves the platform for increase productivity.

FIND A DEALER
snapperpro /

Product Details

500 Hour Oil Change Intervals

Vanguard™ Engines with Oil Guard System reduce maintenance time and costs by up to 60%.**

Adjustable Operator Platform

The adjustable operator platform system with suspension is adjustable for a large range of weights and operating conditions, optimizing operator comfort and increasing productivity.

Speed Control Setting

The 3-position speed control setting is easy-locking and conveniently located for smooth operation. No tools are required to easily change the control setting for operation in a range of conditions.

Contoured Thigh Pad

Ergonomically designed thigh pad with contoured edges provides superior operator comfort, allowing the operator to easily lean into turns and sloping terrain for easier operation.

Height of Cut Adjustment

Cut height is easily changed from the operator compartment for easy curb climbing and trailer loading. The hand-operated deck lift can change cut height in 1/4" increments from 1.75"-4.5".

Commercial Transaxle

Commercial Hydro-Gear® ZT-3400® transaxles are fully serviceable and designed for high performance.

iCD™ Cutting System

The innovative iCD™ Cutting System allows for better airflow, discharge and superior cut quality.

High Fuel Capacity

A 6-gallon tank is centrally located in the operator tower for consistent balance. The fuel filler neck is conveniently located on the side of the unit for easy fuel refill.

Part Number 5901802
Engine Brand Vanguard® 810cc EFI
HP (gross) * 28.0
Displacement (cc) 810
Number of Cylinders 2
Oil Guard System Standard
Fuel Tank Capacity (gal) 8
Starting Type Electric
Cutting Width (in) 52
Deck Construction iCD™ Cutting System
Height-of-Cut (in) 1.75 - 5
Spindles Aluminum
Suspension Adjustable coil-over-shock, Operator Suspension Platform
Transmission Hydro-Gear® ZT-3400® Transaxles with 7" Cooling Fans
Drive Axles 1.125
Drive Tires (in) 23 x 10.5-12
Caster Tires (in) 13 x 5-6, flat-free
Ground Speed - Fwd (mph) 0-10
Ground Speed - Rev (mph) 0-5
Overall Length (in) 67
Overall Width (in) deflector down / deflector up (model) 65/54
Dry Weight (lbs) 921
Seat Package N/A
Certified Rollover Protection System (ROPS) N/A
Instrumentation Engine and PTO hour meter, fuel level gauge
Controls/Safety Group Operator presence in platform, Parking brake safety circuit for starting engine, Automatic PTO restart
Parking Brake/Safety Circuit Internal Transaxle
Warranty (Engine) * 3-Year Limited Manufacturer's Warranty
Warranty (Balance of Machine) ** 4-Year Limited Warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator's manual for complete details.

*All power levels are stated gross horsepower at 3600 RPM per SAE J1940 as rated by Briggs & Stratton **See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.

Part Number 5901803
Engine Brand Vanguard® 810 cc EFI
HP (gross) * 28.0
Displacement (cc) 810
Number of Cylinders 2
Oil Guard System Standard
Fuel Tank Capacity (gal) 8
Starting Type Electric
Cutting Width (in) 61
Deck Construction iCD™ Cutting System
Height-of-Cut (in) 1.75 - 5
Spindles Aluminum
Suspension Adjustable coil-over-shock, Operator Suspension Platform
Transmission Hydro-Gear® ZT-3400® Transaxles with 7" cooling fans
Drive Axles 1.125
Drive Tires (in) 23 x 10.5-12
Caster Tires (in) 13 x 5-6, flat-free
Ground Speed - Fwd (mph) 0-10
Ground Speed - Rev (mph) 0-5
Overall Length (in) 72
Overall Width (in) deflector down / deflector up (model) 77/64
Dry Weight (lbs) 998
Seat Package N/A
Certified Rollover Protection System (ROPS) N/A
Instrumentation Engine and PTO hour meter, fuel level gauge
Controls/Safety Group Operator presence in platform, Parking brake safety circuit for starting engine, Automatic PTO restart
Parking Brake/Safety Circuit Internal Transaxle
Warranty (Engine) * 3-Year Limited Manufacturer's Warranty
Warranty (Balance of Machine) ** 4-Year Limited Warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Coverage on other components varies, please see operator's manual for complete details.

*All power levels are stated gross horsepower at 3600 RPM per SAE J1940 as rated by Briggs & Stratton **See operator's manual or dealer for complete warranty details. Refer to engine operator's manual for engine warranty.

MULCH KIT

Select kits include dedicated mulching blades, baffles, hardware and instruction sheet.

STRIPE KIT

Rubber flap system lays down clippings to create eye catching grass patterns across the landscape.
